技術參數:
型號 Moble | 2412 | |
最高速度(張 / 分) Maximum speed (sheets/minute) | 80 | |
經濟速度(張 / 分) Economic speed (sheet / minute) | 50 | |
橫向最大進紙尺寸 Horizontal maximum feed size(mm) | 2300 | |
橫向最小進紙尺寸 Horizontal minimum feed size(mm) | 650 | |
縱向最大進紙尺寸 Longitudinal maximum feed size(mm) | 1150 | |
縱向最小進紙尺寸 Vertical minimum feed size(mm) | 300 | |
箱高最小 Box height minimum (mm) | 140 | |
箱高最大 Maximum box height(mm) | 400-500 | |
壓線精度 Pressure line accuracy(mm) | ±0.5 | |
紙板厚度 Cardboard thickness(mm) | 3-15 | |
總功率 Total power(kw) | 7 | |
外形尺寸 Dimensions(mm) | 3500-3000-1200 |
